AECW007

3G 4G 5G LTE Cellular Swivel Foldable Blade Antenna for Trail Camera or Outdoor Mobile Security Camera

LTE/CELLULAR

Single External Antennas

Download

Datasheet

Buy Samples

Coming soon

Dealers

Coming soon

Aboosty is ready to help you tackle various wireless issues.

3G 4G 5G LTE Cellular Swivel Foldable Blade Antenna for Trail Camera or Outdoor Mobile Security Camera

SKU: AECW007 Category: External Antennas Tags: 4G/3G/LTE/GSM, 5G NR

Product Overview

Key Features

Description

Specification

Applications

4.5 dBi Peak Gain

Dipole Antenna — Ground Plane Independent

Connector Mount, Direct Mount

Rotatable: 180° Horizontal, 90° Vertical For Compact Multi-Antenna Setups

RoHS Compliant

Operating Frequency: 617-960 MHz | 1710-6000 MHz
Dimensions: 195 x 38.3 x 14.5 mm

The Aboosty AECA015 is a high-performance dipole antenna that covers frequencies from 698 to 6000 MHz, including Sub 6GHz, 5G/4G, and ISM bands. It provides exceptional efficiency and wideband coverage, making it ideal for IoT and high-speed data applications. The antenna features ground-plane independence, a swivel SMA(M) connector with a robust 90° hinge, and supports 3G/2G functionalities. Its omnidirectional design ensures stable radiation patterns across all bands. Designed to reduce lifetime costs for M2M and mobile device installations, the AECA015 offers reliable performance and easy installation, maintaining robust communications even in challenging coverage areas.

Packaging Included: 1 x 5G Blade Antenna (Black)

LABEL

VALUE

Certificates Acquired

RoHS Compliant

Length (mm)

195

Width (mm)

38.3

Height (mm)

14.5

Product Weight (g)

Freq. (MHz)

617-6000

Technology Type

4G/3G/LTE/GSM, 4G 3G/NB-lot, 5G NR, 5G LTE

Operating Temperature (℃)

-40°C to +85°C

Markets

Transportation, Smart Industrial, Smart Cities, Mobility and Infrastructure, Mobile Communication, Public Safety

Antenna Type

Dipole

Connector Style

Right Angle, Straight

Radiation Pattern

Omnidirectional

Polarity

Linear

Max Effi. (%)

Peak Gain

4.5 dBi

VSWR

3.0:1

Impedance (Ω)

Ingress/Impact

N/A

Termination Style

Connector

Antenna Connector Type

SMA-Male

Cable Type

N/A

Mechanical Style

Blade

Mounting Style

Direct Mount

Customization Option

Logo, Packaging, Connectors

Sub 6GHz, 5G & 4G LTE Network Connectivity
Access points, routers and small base station
Mobile Devices
IoT Devices
Automotive Communication
Public Safety Equipment
Home and Office Wireless Networks

Part Number

User Story

Model

Description

Note

AECW007

External 5G Swivel Blade Dipole Antenna

M04-0103330R0A

Customization supported
